FFS-5000s Fusion Splicer

98,000.00

Out of stock

The Star FFS-5000s Fusion Splicer is the revolutionary FTTX Fusion Splicer, the first flat-screen machine in India with an inbuilt optical power meter, and the VFL.The FFS-5000 has an ergonomic design, though not as distinctive as that of the Visual fault locator, which is our latest developed product.

It is more compact and smaller in size and has a high power lithium-ion rechargeable battery with a capacity for up to 200 times of continuous splicing and heating after fully charging. The FFS-5000, one of the most advanced flat-screen fusion splicers on the market, is an integrated device featuring a digital camera for optical power measurements.

Out of stock

Category: Brand:

Description

The Star FFS-5000s Fusion Splicer has an inbuilt optical power meter and is the first revolutionary flat-screen machine in India with an ergonomic design. Newly developed technology provides strong wind and dust resistance.It is the core-to-core alignment flat screen splicing machine with the German V-Groove Core Alignment Splicing Method.

Truly light weight and handy in size, with an adjustable strap hanger and outstanding magnification.The display is crystal clear with its high resolution screen. The complete setups that we supply are built to last longer and have ease of operation, efficient performance, low maintenance, and long service lives.It was designed and developed in collaboration with many technicians and engineers who had on-site operational experience with other splicing machines available prior to the market introduction of the Star FFS -5000s.

General
Splicer Type Single Fiber Fast Fusion Splicer
Fiber Alignment High Precision PAS Alignment
Applicable Fibers Single / SMF (G.652/652D), MMF (G.651), DSF (G.653), NZDSF (G.655), G657A, G657B etc.
Splicing Time 9 Sec. [SM Fast] Program
Heating Time 13 Sec. (Adjustable) Sleeve 60mm, Sleeve 40mm Coating
Splice Loss Low Loss Joining: Average – 0.02db (SMF), 0.01db (MMF), 0.04db (NZ/DS)
Heating Programs 30 Pre Set Program & User Definable
Cleave Length 5mm to 16mm
Splicing Programs 30 Pre Set Program & 100 User Definable
Splice Data Storage 10000 Results
Tension 2N
Screen 4.3 inch High Definition LCD Colour Screen
Fiber Magnification 300x for X or Y single axis view, 150x for both X&Y dual axis view
Loss Estimation Provided
Electrode Life 5000 arc discharges
Operating Condition Altitude 0~5500m, Humidity 0~95%, Temperature -20 to +60 Degrees Centigrade & Wind Velocity up to 15 m/sec
Power Supply AC to DC Adaptor 100-240v, 50/60Hz & 12V Car Charger Type Power Adaptor
Battery Parameters 4400mAh High Capacity Li-Ion Battery
Port DC Charging, USB 2.0
Size & Weight (210x130x145) mm (1.1)kg (1.3kg with battery)
Holder Type Multi-functional Fiber Holder for Easy Splice of Couplers, Patch Cords & All Fiber Types
Durability Shock Resistance, Dust Resistance and Water Resistance
Battery Usage Typical Operating More than 150 (splice / heat shrink) on a Single Charge of 3 hours

Features

  • In Built VFL
  • In Built OPM
  • Strong Built Quality
  • Bright Night Led
  • Core Alignment
  • Fast Arm Cortex Cpu
  • Long Life Performance
  • Long Life Electrodes
  • Ultra-Light & Small-Main Frame
  • Super-Fast Splice & Heating Function

Standard Package

  • Optical Fiber Fusion Splicer
  • AC Power Adaptor/Charger
  • Battery Pack
  • High Precision Fiber Cleaver
  • Alcohol Dispenser
  • Fiber Striper
  • Car Charger
  • Cooling Tray
  • Hard Carrying Case
